TEAC TN-4D-SE Direct Drive Turntable
Description
The TEAC TN-4D-SE Direct Drive Turntable combines the speed accuracy of a modern direct-drive system with the refinement expected from a premium Hi-Fi turntable. Featuring a crystal-locked brushless DC motor, a SAEC-designed knife-edge tonearm, and a factory-installed SUMIKO Oyster moving magnet cartridge, it delivers exceptional stability, precise tracking, and engaging musical performance. With its built-in phono preamp and elegant low-profile design, the TN-4D-SE integrates effortlessly into both modern and traditional stereo systems.
Why It Stands Out
Crystal-Locked Direct-Drive Precision
The TN-4D-SE features TEAC's newly developed brushless DC direct-drive motor with a computer-controlled feedback system. This design delivers excellent speed stability while eliminating the cogging often associated with traditional direct-drive turntables, resulting in smooth, accurate vinyl playback.
SAEC-Designed Knife-Edge Tonearm
Developed in collaboration with renowned Japanese tonearm specialist SAEC, the static-balanced S-shaped tonearm features a knife-edge pivot bearing that minimizes friction and improves tracking performance. The result is greater detail, improved dynamics, and more accurate reproduction of your records.
Premium SUMIKO Oyster Cartridge
The factory-installed SUMIKO Oyster moving magnet cartridge delivers a rich, dynamic presentation with impressive clarity and a wide soundstage. Since the tonearm uses a standard removable headshell, upgrading to a different cartridge in the future is quick and easy.
Built-In Switchable Phono Preamp
The integrated MM phono preamp allows the TN-4D-SE to connect directly to powered speakers, integrated amplifiers, or receivers with line-level inputs. Simply switch between PHONO and LINE outputs to match your system without requiring an external phono stage.
Built for Accurate Vinyl Playback
A high-inertia die-cast aluminum platter, precision anti-skating adjustment, adjustable tracking force, and shock-absorbing feet work together to reduce unwanted vibration while preserving musical detail and protecting your record collection.
Elegant Low-Profile Design
Unlike many direct-drive turntables, the TN-4D-SE uses a slim brushless motor that allows for a sleek, modern profile without compromising performance. Its high-density MDF plinth and premium finish make it an attractive addition to any listening room.
The TN-4D-SE stands out because it successfully combines the precision of a direct-drive turntable with the refinement typically associated with premium belt-drive designs. The crystal-locked motor delivers outstanding speed stability, while the collaboration with SAEC and the factory-installed SUMIKO Oyster cartridge elevate its musical performance well beyond what you'd expect at this price. If you're looking for a direct-drive turntable that offers excellent engineering, elegant styling, and genuine audiophile performance, the TN-4D-SE is one of the strongest choices in its class.
Specifications
| TURNTABLE | |
| Drive Type | Direct Drive |
| Motor | Brush-less DC Motor |
| Supported Speeds | 33⅓ RPM, 45 RPM |
| Wow & Flutter | 0.1% |
| Signal-to-Noise Ratio | 67dB or Higher (A-Weighted, 20kHz LPF) |
| Platter Material | Aluminium Die-Cast |
| Platter Diameter | 30cm |
| TONEARM | |
| Type | S-Shaped, Static-Balanced |
| Effective Arm Length | 223mm |
| Needle Pressure Range | 0g to 5.0g |
| Compatible Cartridge Weight | 3.0g to 12.0g 14g to 23g (Including Headshell) |
| CARTRIDGE | |
| Type | MM-Type (SUMIKO Oyster Factory Installed) |
| Output Voltage | 4.0mV (1kHz) |
| Recommended Tracking Force | 1.5g to 2.5g (Recommended: 2.3g) |
| Cartridge Weight | 5.3g |
| Headshell Weight | 11g (Including Nuts, Screws and Wires) |
| Compatible Stylus | Styluses for SUMIKO Oyster |
| CONNECTIONS | |
| Analog Audio Output | RCA Pin Jack × 1 Pair (PHONO/LINE Switchable) |
| Phono Output Voltage | 4.0mV (1kHz) |
| Line Output Voltage | 224mV (-13dBV) |
| GENERAL | |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Power Consumption | 2W |
| Standby Power | 0.5W or Less |
| Product Dimensions | 420 × 117 × 356 mm (W × H × D) 16.5 × 4.6 × 14.0 in (W × H × D) |
| Weight | Approx. 6.1kg (13.5 lbs) |
| Included Accessories | Felt Mat, EP Adapter, Counterweight, Headshell (SUMIKO Oyster Installed), Platter, Dust Cover, Hinges × 2, RCA Audio Cable with Ground Terminal, AC Adapter (GPE036W-24015), Owner's Manual (Including Warranty Card) |
