TEAC TN-3B-SE Manual Belt-Drive Turntable
Description
The TEAC TN-3B-SE Manual Belt-Drive Turntable combines precision engineering with elegant design to deliver an engaging vinyl listening experience. Featuring a SAEC-designed knife-edge tonearm, an Audio-Technica AT-VM95E moving magnet cartridge, and a switchable built-in phono preamp, it offers exceptional performance straight out of the box. Whether you're building your first Hi-Fi system or upgrading an existing setup, the TN-3B-SE delivers accurate tracking, smooth rotation, and the warm, detailed sound that makes vinyl so enjoyable.
Why It Stands Out
SAEC-Designed Precision Tonearm
Developed in collaboration with renowned Japanese tonearm specialist SAEC, the TN-3B-SE features a static-balanced S-shaped tonearm with a knife-edge pivot bearing. This advanced design improves tracking accuracy, reduces friction, and extracts more musical detail from every record.
Smooth Belt-Drive Performance
The external belt-drive system powers the outer edge of the die-cast aluminum platter, reducing motor vibration and cogging for more stable rotation and improved speed accuracy. The result is cleaner playback with greater musical realism.
Audio-Technica AT-VM95E Cartridge Included
The factory-installed Audio-Technica AT-VM95E moving magnet cartridge delivers detailed, balanced sound right out of the box. Its interchangeable stylus design also provides an easy upgrade path as your vinyl system evolves.
Built-In Switchable Phono Preamp
A high-quality MM phono preamp with a premium NJM8080 op-amp allows direct connection to powered speakers, integrated amplifiers, or receivers with or without a dedicated phono input. This flexibility makes the TN-3B-SE easy to integrate into virtually any audio system.
Built for Accurate Vinyl Playback
Adjustable tracking force, anti-skating control, gold-plated RCA outputs, and a precision-machined aluminum platter work together to ensure consistent playback while protecting your records and stylus.
Elegant Construction
The high-density MDF plinth, multi-layer gloss finish, vibration-resistant feet, and honeycomb-reinforced bottom panel help minimize unwanted resonance while adding a refined appearance that complements any Hi-Fi system.
RockOnAV's Take
The TN-3B-SE is one of the strongest values in TEAC's turntable lineup. What sets it apart isn't just its elegant design—it's the engineering underneath. The collaboration with SAEC on the tonearm, combined with the excellent Audio-Technica AT-VM95E cartridge and high-quality built-in phono stage, gives this turntable performance that exceeds what you'd typically expect at its price point. For music lovers looking to move beyond entry-level vinyl playback, the TN-3B-SE offers an outstanding balance of precision, musicality, and long-term upgrade potential.
Specifications
| TURNTABLE | |
| Drive Type | Belt-Drive (External Drive) |
| Motor | DC Motor |
| Supported Speeds | 33⅓ RPM, 45 RPM |
| Wow & Flutter | 0.1% or Less |
| Signal-to-Noise Ratio | 67dB (A-Weighted, 20kHz LPF) |
| Platter Material | Aluminum Die-Cast |
| Platter Diameter | 30cm |
| TONEARM | |
| Type | S-Shape, Static-Balanced |
| Effective Arm Length | 223mm |
| Needle Pressure Range | 0g to 5.0g |
| Compatible Cartridge Weight | 3.0g to 12.0g 14g to 23g (Including Headshell) |
| CARTRIDGE | |
| Type | MM-Type |
| Output Voltage | 4.0mV (1kHz, 5cm/sec.) |
| Recommended Tracking Force | 1.8g to 2.2g (2.0g Recommended) |
| Cartridge Weight | 6.1g |
| Headshell Weight | 11g (Including Screws, Nuts and Wires) |
| Compatible Stylus | Audio-Technica AT-VMN95E (Approx. 300-Hour Stylus Life) |
| CONNECTIONS | |
| Analog Audio Output | Gold-Plated RCA Pin Jack × 1 Pair |
| Phono Output Voltage | 4.0mV (1kHz) |
| Line Output Voltage | 224mV (-13dBV) |
| GENERAL | |
| Power Supply | AC 100-240V, 50/60Hz |
| Power Consumption | 1.5W |
| Standby Power | 0.5W |
| Product Dimensions | 420 × 117 × 356 mm (W × H × D) 16.5 × 4.6 × 14.0 in (W × H × D, Including Protrusions) |
| Weight | Approx. 5.0kg (11.0 lbs) |
| Included Accessories | Felt Mat, EP Adapter, Counterweight, Headshell (AT-VM95E Installed), Platter, Dust Cover, Hinges × 2, RCA Audio Cable with Ground Terminal, AC Adapter (GPE053A-V120050), Owner's Manual (Including Warranty Card) |
