TEAC AD-850-SE Cassette Deck & CD Player
Description
The TEAC AD-850-SE Cassette Deck & CD Player is the perfect solution for music lovers who still enjoy physical media. Combining a high-quality CD player, cassette deck, USB playback, and direct USB recording into one convenient component, it makes it easy to enjoy, preserve, and share your music collection. Whether you're revisiting treasured cassette tapes, playing your favorite CDs, or converting recordings to digital files, the AD-850-SE delivers exceptional versatility with the reliability and ease of use that TEAC is known for.
Why It Stands Out
Enjoy Two Classic Music Formats
The AD-850-SE combines a full-featured CD player with a two-head cassette deck, allowing you to enjoy both CDs and cassette tapes from a single component. It's an ideal choice for anyone with an existing music collection who wants one easy-to-use playback solution.
Record Directly to USB
Preserve your favorite music without using a computer. The AD-850-SE can record CDs, cassette tapes, or external analog sources directly to a USB flash drive as MP3 files, making it simple to digitize older recordings for modern listening.
Create Your Own Mix Tapes
Record from CD, USB, or external audio sources directly to cassette, or transfer cassette recordings to USB. Whether you're creating custom playlists or preserving irreplaceable recordings, the AD-850-SE offers flexible recording options that are increasingly difficult to find today.
Adjustable Pitch Control
The cassette deck includes ±10% pitch control, allowing you to fine-tune playback speed. It's especially useful for language learning, music practice, transcription, or restoring older tapes that may play slightly fast or slow.
Built-In Microphone Input
A front-panel microphone input with adjustable echo makes the AD-850-SE suitable for karaoke, announcements, voice recording, and public presentations, adding another level of versatility beyond traditional music playback.
Timer Recording & Playback
Compatible with external audio timers, the AD-850-SE supports scheduled playback and recording, making it suitable for broadcast applications, educational environments, and unattended recording sessions.
Designed for Long-Term Reliability
Built with TEAC's decades of expertise in analog and digital audio, the AD-850-SE offers dependable performance, intuitive controls, and a familiar component-style design that integrates easily into both modern and classic Hi-Fi systems.
RockOnAV's Take
The AD-850-SE fills a unique role in today's audio world. While streaming dominates modern listening, many music lovers still own valuable CD and cassette collections that deserve to be enjoyed. The AD-850-SE makes that easy by combining playback, recording, and USB archiving into one reliable component. Whether you're preserving old recordings, creating mix tapes, or simply rediscovering your music library, it offers exceptional versatility at an affordable price. It's one of the few products available today that truly bridges classic and modern audio formats.
Specifications
| CASSETTE DECK | |
| Track System | 4-Track, 2-Channel Stereo |
| Head Construction | Recording/Playback Head × 1, Erase Head × 1 |
| Compatible Tape Types | C-46, C-60, C-90 |
| Tape Speed | 4.76cm/sec |
| Motor | DC Servo Motor × 1 |
| Pitch Control | Approx. ±10% (Playback Only) |
| Wow & Flutter | 0.25% (WRMS) |
| Frequency Response (Chrome Tape) | 50Hz to 12kHz ±3dB |
| Frequency Response (Normal Tape) | 50Hz to 12kHz ±3dB |
| Signal-to-Noise Ratio | 59dB (3% THD Level, WTD) |
| Fast Winding Time | Approx. 120 Seconds (C-60 Tape) |
| Line Input | RCA, 462mV (50kΩ or Higher Input Impedance) |
| Line Output | RCA, 462mV (50kΩ or Higher Load Impedance) |
| CD PLAYER | |
| Pickup | 3-Beam Semiconductor Laser |
| Digital Filter | 8× Oversampling Digital Filter |
| Frequency Response | 20Hz to 20kHz ±2dB |
| Total Harmonic Distortion | 0.02% or Less (1kHz) |
| Signal-to-Noise Ratio | 87dB or Higher (IHF-A) |
| Analog Output | RCA, 2.0V |
| USB | |
| USB Interface | USB 1.1 Full Speed (12Mbps) |
| Playback Format | MP3 |
| Playback Frequency Response | 20Hz to 20kHz ±2dB |
| Playback Signal-to-Noise Ratio | 85dB or Less |
| Playback Bit Rate | 8kbps to 320kbps |
| Recording Format | MP3 |
| CD to USB Frequency Response | 20Hz to 15kHz ±3dB |
| Line In to USB Frequency Response | 100Hz to 15kHz ±3dB |
| Recording Signal-to-Noise Ratio | 85dB or More |
| Recording Bit Rate | 128kbps |
| MICROPHONE INPUT | |
| Connector | 6.3mm (1/4") Mono Phone Jack |
| Nominal Input Level | 0.78mV (−60dBm) |
| Input Impedance | 47kΩ or Higher |
| Power Supply Function | None |
| POWER & GENERAL | |
| Power Supply | AC 120V, 60Hz; AC 220V, 60Hz; AC 230V, 50Hz |
| Power Consumption | 14W |
| Dimensions | 435 × 145 × 288 mm (W × H × D, Including Protrusions) |
| Weight | 4.8kg (10.6 lbs) |
| Operating Temperature | 5°C to 35°C |
| Operating Humidity | 5% to 85% (Non-Condensing) |
| Storage Temperature | −20°C to 55°C |
| Included Accessories | Remote Control (RC-1329), AAA Batteries × 2, RCA Audio Cables × 2, Owner's Manual (Warranty Card), Quick Start Guide for Recording |
