Parasound NewClassic 2125 V2 Two-Channel Power Amplifier
Great sound with added power
Features
- THX Ultra2 certified
- 150 watts x 2 into 8 Ω (all channels driven)
- 225 watts x 2 into 4 Ω or 2 Ω (all channels driven)
- 400 watts x 1 bridged into 8 Ω or 4 Ω
- 35 amps peak current per channel
- 2 Ohm stable operation with load selector switch
- Two pairs of speaker outputs with front panel A/B buttons
- Rear-mounted lockout switch disables front A/B buttons
- High pass filter, switchable for 20Hz or 40Hz
- Automatic on/off by DC trigger with looping output
- Automatic on/off by audio signal with 2 sensitivity settings
- Fully discrete circuitry with high current toroid transformer
- Bridging switch for stereo or mono operation
- Efficient, low heat design
- DC Servo and relay protection circuits
- Rear-mounted left and right gain controls
- Standby, channel status and high temperature indicators
- Gold-plated RCA input jacks
- Heavy duty 24k gold-plated 5-way speaker terminals
- 115/230v selector on rear panel
- 2U rack mount kit available separately (Model RMK22)
Specifications
| All Channels Driven | 150 watts x 2, 8Ω 225 watts x 2, 4Ω 225 watts x 2, 2Ω (Load switch set to 2-3Ω) |
| Bridged Mono | 400 watts x 1, 8Ω 400 watts x 1, 4Ω (Load switch set to 2-3Ω) |
| Current Capacity | 35 amps peak per channel |
| Frequency Response | 20 Hz - 50 kHz, +0/-3 dB, 1 watt Dynamic Headroom - 1.3 dB |
| Total Harmonic Distortion | 0.25% at full rated output 0.015% at average listening levels |
| IM Distortion | 0.05 % |
| Transient IM Distortion | Not measurable |
| S/N Ratio | 114 dB at rated output, IHF A-weighted 106 dB at rated output, unweighted 93 dB at 2.828 V output, IHF A-weighted 84 dB at 2.828 V output, unweighted |
| Input Impedance | 33 k Ω |
| Input Sensitivity | 1 V in for 28.28 V out, THX standard |
| Inter-Channel Crosstalk | 85 dB @ 1 kHz 73 dB @ 10 kHz 67 dB @ 20 kHz |
| Damping Factor | Over 150 at 20 Hz |
| 12V Trigger Turn On | DC 9 – 12V, 15 mA |
| Audio Turn On | Quieter: 1 mV Louder: 6 mV |
| AC Power Requirement | 110 - 120 V / 220 - 240 V, 50 - 60 Hz 0.5 watts standby 32 watts Idle (no audio) 550 watts full output |
| Dimensions | Width: 17.25" (437 mm) Depth: 16" (406 mm) with cables connected Height: 4.25" (108 mm) with feet Height: 3.5" (88.2 mm) panel only, 2U |
| Net Weight | 27 lbs (12.3 kg) |
| Rack Mount Accessory | May be Purchased Separately: RMK22 |
