Focal 100 IWLCR 5 In-Wall 2-Way Loudspeaker (Each)
D'appolito 2-way wall-mounted speaker
Thanks to its sound performance and compactness, this LCR (left, center, right) integrated speaker is the perfect complement for home theater use, but is also compatible with any room in the house. Its Appolito configuration, with the tweeter placed between two bass-midrange drivers, ensures high power handling and better directivity control.
PRECISE ACOUSTICS
100 IWLCR5 features an adjustable inverted dome tweeter. Its 13 cm loudspeakers feature Polyglass diaphragms for excellent damping and well-defined midrange. Correctors are used to equalize high and mid frequencies, for an ever more appropriate acoustic response.
POLYVALENCE
The loudspeaker can be used horizontally for Home Cinema installations. A three-position switch allows you to define the left, center or right function, to guarantee identical tonal balance at the listening point.
DESIGN AND DISCRETION
Thanks to its shallow depth and ready-to-paint magnetic grille, 100 IWLCR5 will fit in anywhere, easily and discreetly.
Key Points
• Product designed and developed in France by Focal
• Compact product with shallow mounting depth
• Possible to connect two loudspeakers to the same amplifier output
• Ready-to-paint grille
Specifications
Technical Specifications
| Type | D'appolito In-wall 2-way |
|---|---|
| Drivers |
2x5" (13cm) Polyglass Midbass 1" (25mm) AI inverted dome Tweeter |
| Sensitivity (2.83V/1m) | 90.5dB |
| Frequency response (+/-3dB) | 55Hz-23kHz |
| Low frequency point (-6dB) | 43Hz |
| Nominal impedance | 8Ω |
| Minimal impedance | 3.8Ω |
| Recommended amplifier power | 25-120W |
| External dimensions (Ø/Depth) | 175/16"x613/16"x33/8" (440x173x86mm) |
| Cut-Out diameter | 165/16"x513/16" (415x147mm) |
| Depth from wall | 31/4" (83mm) |
| Net weight (with front grille) | 3.89lbs (2.90kg) |
| Packing dimensions (WxDxH) | 193/16"x811/16"x411/16" (487x220x119mm) |
| Total weight (with packaging) | 7.6lbs (3.45kg) |
