Focal 100 ICW5 In-Wall / In-Ceiling 2-Way Coaxial Loudspeaker (Each)

Focal 100 ICW5 In-Wall / In-Ceiling 2-Way Coaxial Loudspeaker (Each)
2-way coaxial speaker
Dedicated to residential use, the 100 ICW5 coaxial wall or ceiling speaker with its 13 cm driver stands out for its sound performance and discretion. Proven technology, discreet, efficient design, a host of features, easy, appropriate use: let the 100 Series surprise you and create the installation to suit your needs and desires.
POLYVALENCE
Flush-mountable in walls or ceilings from 8 to 35 mm thick, 100 ICW5 is perfect for sound diffusion in high-traffic areas (hallway, living room), for stereo use (bedroom, kitchen...) or in Home Cinema configuration (living room, dedicated installation). The tweeter level can be adjusted to match the acoustics of your room.
MOISTURE RESISTANCE
Thanks to the "tropicalization" of Polyglass midrange drivers, 100 Series products can be adapted to humid environments, such as bathrooms.
SIMPLICITY AND DISCRETION
With its shallow mounting depth and optimized mounting brackets, the loudspeaker is quick and easy to install. The unibody frame and ready-to-paint magnetic grilles ensure discreet integration in any living space.
Key Points
• Product designed and developed in France by Focal
• Compact product with shallow mounting depth
• For in-ceiling or in-wall loudspeakers (1 product, 2 uses)
• Possible to connect two loudspeakers to the same amplifier output
• Ready-to-paint grille
Specifications
Technical Specifications
Type | In-wall/In-celling - 2-way coaxial |
---|---|
Drivers |
5" (13cm) Polyglass Midbass 1" (25mm) AI inverted dome Tweeter |
Sensitivity (2.83V/1m) | 88dB |
Frequency response (+/-3dB) | 65Hz-23kHz |
Low frequency point (-6dB) | 56Hz |
Nominal impedance | 8Ώ |
Minimal impedance | 7.3Ώ |
Recommended amplifier power | 15-100W |
External dimensions (Ø/Depth) | 71/4"x327/64" (184x87mm) |
Cut-Out diameter | 619/64" (160mm) |
Depth from wall | 315/64" (82mm) |
Net weight (with front grille) | 3.19lbs (1.45kg) |
Packing dimensions (WxDxH) | 95/8"x95/8"x65/16" (245x245x161mm) |
Total weight (with packaging) | 4.52lbs (2.05kg) |
Description
Description
Focal 100 ICW5 In-Wall / In-Ceiling 2-Way Coaxial Loudspeaker (Each)
2-way coaxial speaker
Dedicated to residential use, the 100 ICW5 coaxial wall or ceiling speaker with its 13 cm driver stands out for its sound performance and discretion. Proven technology, discreet, efficient design, a host of features, easy, appropriate use: let the 100 Series surprise you and create the installation to suit your needs and desires.
POLYVALENCE
Flush-mountable in walls or ceilings from 8 to 35 mm thick, 100 ICW5 is perfect for sound diffusion in high-traffic areas (hallway, living room), for stereo use (bedroom, kitchen...) or in Home Cinema configuration (living room, dedicated installation). The tweeter level can be adjusted to match the acoustics of your room.
MOISTURE RESISTANCE
Thanks to the "tropicalization" of Polyglass midrange drivers, 100 Series products can be adapted to humid environments, such as bathrooms.
SIMPLICITY AND DISCRETION
With its shallow mounting depth and optimized mounting brackets, the loudspeaker is quick and easy to install. The unibody frame and ready-to-paint magnetic grilles ensure discreet integration in any living space.
Key Points
• Product designed and developed in France by Focal
• Compact product with shallow mounting depth
• For in-ceiling or in-wall loudspeakers (1 product, 2 uses)
• Possible to connect two loudspeakers to the same amplifier output
• Ready-to-paint grille
Specifications
Specifications
Technical Specifications
Type | In-wall/In-celling - 2-way coaxial |
---|---|
Drivers |
5" (13cm) Polyglass Midbass 1" (25mm) AI inverted dome Tweeter |
Sensitivity (2.83V/1m) | 88dB |
Frequency response (+/-3dB) | 65Hz-23kHz |
Low frequency point (-6dB) | 56Hz |
Nominal impedance | 8Ώ |
Minimal impedance | 7.3Ώ |
Recommended amplifier power | 15-100W |
External dimensions (Ø/Depth) | 71/4"x327/64" (184x87mm) |
Cut-Out diameter | 619/64" (160mm) |
Depth from wall | 315/64" (82mm) |
Net weight (with front grille) | 3.19lbs (1.45kg) |
Packing dimensions (WxDxH) | 95/8"x95/8"x65/16" (245x245x161mm) |
Total weight (with packaging) | 4.52lbs (2.05kg) |
